| Numero ng Bahagi : | EEE-FT1E330AR |
|---|---|
| Tagagawa / Brand : | Panasonic |
| Paglalarawan : | CAP ALUM 33UF 20% 25V SMD |
| Katayuan ng RoHs : | Lead libreng / RoHS compliant |
| Available ang Dami | 437064 pcs |
| Mga Datasheet | 1.EEE-FT1E330AR.pdf2.EEE-FT1E330AR.pdf3.EEE-FT1E330AR.pdf4.EEE-FT1E330AR.pdf5.EEE-FT1E330AR.pdf |
| Boltahe - Rated | 25V |
| pagpapaubaya | ±20% |
| Ibabaw Mount Land Size | 0.169" L x 0.169" W (4.30mm x 4.30mm) |
| Sukat / Dimension | 0.157" Dia (4.00mm) |
| serye | FT |
| Ripple Current @ Low Frequency | 104mA @ 120Hz |
| Ripple Current @ High Frequency | 160mA @ 100kHz |
| Ratings | AEC-Q200 |
| polariseysyon | Polar |
| packaging | Tape & Reel (TR) |
| Package / Kaso | Radial, Can - SMD |
| Ibang pangalan | EEEFT1E330AR PCE5004TR |
| operating Temperature | -55°C ~ 105°C |
| Salalayan Type | Surface Mount |
| Ang Sensitivity Level (MSL) | 1 (Unlimited) |
| Tagagawa Standard Lead Time | 19 Weeks |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Lead Spacing | - |
| Lead Libreng Status / Katayuan ng RoHS | Lead free / RoHS Compliant |
| Taas - Makaupo (Max) | 0.240" (6.10mm) |
| ESR (Katumbas Series pagtutol) | 850 mOhm @ 100kHz |
| Detalyadong Paglalarawan | 33µF 25V Aluminum Electrolytic Capacitors Radial, Can - SMD 850 mOhm @ 100kHz 2000 Hrs @ 105°C |
| kapasidad | 33µF |
| aplikasyon | Automotive |
Panasonic
